Watchnet MPIX-40VDF-NPC36AI

Features
  • 1/1.8” 4Megapixel progressive scan CMOS
  • H.265 & H.264 triple-stream encoding
  • 25/30 fps@2688×1520, 50/60 fps@1080 (1920×1080)
  • Ultra WDR(140dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
  • 3.6 mm fixed lens
  • 1/1 Alarm in/out, 1/1 audio in/out
  • Micro SD memory (Max. 256GB), IP67, IK10, PoE
  • Supports DC 12V (}30%), PoE (802.3af) (Class 0)
  • Pro AI Functions:
    · Face Capture (Detect & Recognition with attributes)
    · Fenced Area protection
    · People Counting Functions
    · Line Crossing (Person & Vehicle Classification)
  • Multiple network monitoring:
    Built-in web server & Multifunction VMS
  • Smart phones compatible
Technical Specifications
Model
 MPIX-40VDF-NPC36AI
Camera
 Fixed Focus
Image Sensor 1/1.8” 4Megapixel progressive scan CMOS
Effective Pixels 2688(H) x 1520(V)
Min. Illumination 0.0002Lux@ F1.0
Electronic Shutter Speed Auto/Manual, 1/3~1/100000s
RAM/ROM 1 GB / 128 MB
Scanning System Progressive
Streaming Triple Stream
Lens
 Max Aperture F1.0
Focal Length Fixed 3.6mm lens
White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Lens Type Fixed
Mount Type Board-in Type
Angle of View H: 93°, V: 50°
Features
 Day/Night Auto(ICR) / Color / B/W
Backlight Compensation BLC / HLC / Ultra WDR (140dB)
Close Focus Distance 2.0 m (6.56 ft)
Gain Control Auto / Manual
White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Noise Reduction 3D DNR
Privacy Masking Off / On (4 Area, Rectangle)
Video
 Video Compression H.265+, H.265, H.264+, H.264, H.264B, H.264H, MJPEG (sub stream)
Image Resolution 2688×1520/2560×1440/2304×1296/1080P
(1920×1080)/1.3M (280×960)/720P (1280×720)/
D1(704×576/704×480)/VGA (640×480)/
CIF(352×288/352×240)
Frame Rate Main Stream: 2688×1520 (1fps-25/30fps)
2560×1440 (1fps-25/30fps)
1920×1080 (1fps-50/60fps)
Sub Stream: D1 (1fps-25/30 fps)
D1 (1fps-50/60fps)
Third Stream: 1080P (1fps-16 fps)
Bit Rate H.264: 32 Kbps-8192 Kbps / H.265: 19 Kbps-8192 Kbps
Edge Storage NAS
Local PC for instant recording
Micro SD card 256G
Artificial Intelligence
 Face Capture Support face image capture
People Counting Support Line crossing/Region/Queueing people counting;
Support 4 accesses independent detection,
4 areas independent detection
Fenced Area Protection Line Crossing, Intrusion (Human & Vehicle classification)
Event Trigger Motion detection, Video tampering, Scene changing,
Network disconnection, IP address conflict, Illegal Access,
Storage anomaly
General Intelligence Object Abandoned / Missing
Network
 Ethernet RJ – 45 (10/100Base -T )
Network Functions HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP,
DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP,
NTP, ICMP, HTTPS, IGMP, 802.1x
Max. User Access 20 Users
Smart Phone iPhone, iPad, Android
ONVIF ONVIF(Profile S/Profile G/Profile T); P2P
Streaming
 Streaming Metod Unicast / Multicast
Audio
 Compression G.711a, G.711Mu, G.726, AAC, G.723
Audio Interface 1/1 channel In/Out
Alarm
 Memory Slot Micro SD, Max 256GB
Alarm 1 channel In: 5mA 5VDC
1 channel Out: 300mA 12V DC
Environmental
 Power Supply DC 12V (+/-30%), AC 24V (+/-30%), PoE (802.3at)(Class 0)
Power Consumption <4.4W
Operating Temp./Hum. Operating Conditions: -30°C~+60°C /-22°F~+140°F, 10%RH~95%RH
Protection Level IP67, IK10
Dimension Φ122.0 mm × 88.9 mm (4.80” × 3.50”)
Net/Gross Weight 0.46 kg (1.01 lb) / 0.62 kg (1.37 lb)
