Watchnet MPIX-40BIMR

Features
  • Motorized IR bullet camera
  • 1/3” 4 Megapixel progressive scan CMOS
  • 5/30fps@4Mp(2688×1520)
  • H.265 & H.264 triple-stream encoding
  • WDR up to 120dB
  • Day/Night(ICR), 3DNR, Auto Iris, AWB, AGC, BLC
  • 2.7mm~13.5mm motorized lens
  • Max. IR LEDs length 50m/164feet
  • 2/1 Alarm in/out, 1/1 audio in/out
  • Micro SD memory, IP67, PoE
  • Multiple network monitoring:
    Built-in web server & Multifunction VMS
  • Smart phones compatible
  • Supports multiple analytic functions.
    For more Information call us to better suit your needs.
Technical Specifications
Model
MPIX-40BIMR
Camera
 Motorized variable focus
Image Sensor 1/3” 4 Megapixel CMOS
Effective Pixels 2688(H) x 1520(V)
Min. Illumination 0.03Lux/F1.4 (Color,1/3s,30IRE)
0.3Lux/F1.4 (Color,1/30s,30IRE)(br) 0Lux/F1.4(IR on)
Electronic Shutter Speed Auto/Manual, 1/3~1/100000s
S/N Ratio >50dB
Scanning System Progressive
IR Distance Distance up to 50m (164ft)
Lens
 Max Aperture F1.4
Focal Length 2.7mm ~ 13.5mm motorized lens
White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Lens Type Motorized / Auto Iris(DC)
Mount Type Board-in Type
Angle of View H: 106°~31°, V:58°~17°
Features
 Day/Night Auto(ICR) / Color/B/W
Backlight Compensation BLC / HLC / WDR (120dB)
Max. IR LEDs Length 50m/164ft
Gain Control Auto / Manual
Noise Reduction 3D
Privacy Masking Up to 4 areas
Video
 Video Compression H.265+/H.265/H.264+/H.264
Image Resolution 4M(2688×1520)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
Frame Rate Main Stream: 4M(1~25/30fps) / Sub Stream: D1(1~25/30fps) / Third Stream: 720P(1~25/30fps)
Bit Rate H.264: 24 ~ 10240Kbps H.265: 14 ~ 9984Kbps
Flip
 0°/90°/180°/270°
Network
 Ethernet RJ-45 (10/100Base-T)
Network Functions HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP
Max. User Access 10 Users / 20 Users
Smart Phone iPhone, iPad, Android
ONVIF ONVIF, PSIA, CGI
Audio
 Compression G.711a / G.711Mu / AAC / G.726
Audio Interface 1/1 channel In/Out
Auxiliary Interface
 Memory Slot Micro SD, Max 128GB
Alarm 2 channel In: 5mA 5VDC / 1 channel Out: 300mA 12VDC
Environmental
 Power Supply DC12V, PoE (802.3af)(Class 0)
Power Consumption <12.95W
OperatingTemp./Hum. -30°C~+60°C /-22F~+140°F, Less than 95%RH
Protection Level IP67, POE
Dimension 273.2mm×95.0mm×95.0mm
(10.76”×3.74”×3.74”)
Net/ Gross Weight 1.11Kg (2.44lb) / 1.51Kg (3.33lb)
