Watchnet MPIX-21MP4X

Features
  • Sony 1/3” Exmor CMOS High definition sensor
  • 2.1Mp Full HD 4x Network PTZ Dome Camera
  • H.264 & MJPEG dual-stream encoding
  • 2.7mm~11mm (4x Optical zoom, 16x Digital zoom))
  • Built-in 2/1 alarm in/out
  • Support intelligent 3D positioning
  • Max. 30fps@1080p(1920×1080)
  • WDR(120dB), Day/Night(ICR), Ultra DNR (2D&3D), Auto iris, Auto focus, AWB, AGC,BLC
  • Multiple network monitoring: Built-in Web viewer and VMS
  • Up to 300 presets, 5 Pattern, 8 Tour, Auto Pan, Auto Scan
  • Micro SD memory, IP66, IK10, PoE
  • Max 100°/s pan speed
  • Supports multiple analytic functions.
    For more information call us to better suit your needs.
Technical Specifications
Model Number
MPIX-21MP4X
Camera
 Image Sensor Sony 1/2.7” Exmor CMOS High definition sensor
Scanning System Progressive scan
Effective Pixels 1920(H) x 1080(V), 2.1 Megapixels
Min Illumination Color: 0.005Lux@F1.6; B/W: 0.0005Lux@F1.6
Electronic Shutter Speed 1/1s ~1/30,000s
IR Distance N/A
Scanning Progressive Scan System
Lens
 Max Aperture F1.6
Focal Length 2.7mm~11mm (4x Optical zoom)
Angle of View H: 112.5° ~ 39°
Focus Control Auto / Manual
Features
 Day/Night Auto(ICR) / Color / B/W
White Balance Auto, ATW, Indoor, Outdoor, Manual
Backlight Compensation BLC / HLC / WDR(120dB)
Noise Reduction Ultra DNR 2D / 3D
Digital Zoom 16x
Privacy Masking Up to 24 areas
Gain Control Auto / Manual
PTZ
 Manual Control Speed Pan: 0.1° ~100° /s;Tilt: 0.1° ~60° /s
Preset Speed Pan:100° /s;Tilt: 60° /s
Pan/Tilt Range Pan: 0° ~ 355°;Tilt: 0° ~ 90°, auto flip 180°
Preset 300
Speed Setup Auto focal length/ speed adaptation
PTZ Mode 5 Pattern, 8 Tour, Auto Pan, Auto Scan
Idle Action Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period
Power up Action Auto restore to previous PTZ and lens status after power failure
Video
 Compression H.265 / H.264 / MJPEG
Resolution 1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) / CIF (352×288/352×240)
Bit Rate H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps
Frame Rate Main Stream: 1080P/720P/D1 (1 ~ 25/30fps)
Sub Stream1: D1/CIF(1 ~ 25/30fps)
Sub Stream2: 720P/D1/CIF (1 ~ 25/30fps)
Network
 Ethernet RJ-45 (10XBase-T/100Base-TX)
ONVIF ONVIF Profile S
Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
Smart Phone iPhone, iPad, Android
Max. User Access 20 users
Audio
 Compression N/A
Auxiliary Interface
 Memory Slot Micro SD, Max 128GB
General
 Power Consumption 5.5W
Power Supply DC12V, 1.5A, P0E (802.3af)
Protection Level IP66, IK10, PoE
Operating temperature -30o to 60 oC (-22oF to 140oF) / Less than 95% RH
Dimensions Φ122(mm) x 89(mm) / Φ4.8” x 3.5”
Net/Gross Weight 0.52kgs / 1.23lb / 0.73kgs / 1.61lb
